Technical Features:
Fully enclosed environmentally friendly compressor refrigeration system, CFC free.● Temperature range: -10~100 ℃ (choose pure water, ethylene glycol, alcohol as the medium according to the temperature range)
Test blackbody device: emissivity ≥ 0.997
Temperature uniformity/fluctuation: ± 0.01~0.005 ℃
● Temperature control function: Equipped with an integrated next-generation PID automatic temperature control program, with a built-in high-precision PT100 temperature sensor rated AAA. Equipped with a large screen high brightness LCD screen, displaying in both Chinese and English, with a digital resolution of 0.0001 ℃, ensuring precise and stable temperature control.
Inner groove size (mm) (length X width X groove depth): 300 × 250 × 200, working groove opening: 235X160 (mm2).
Internal circulation function: Adopting a non heat centrifugal circulation pump to avoid the influence of traditional water pumps on the tank temperature field due to their own heat generation. The internal circulation system is designed based on the principle of porous U-shaped reflux circulation, achieving turbulent and highly uniform flow and temperature fields within the tank.
The body shell adopts anti-aging electrostatic spraying technology, and the inner liner and tabletop are made of high-quality S304 brushed stainless steel material.
The finely crafted front panel and tabletop of the chassis, coupled with a unique humanized R-rounded design structure, can prevent operators from being accidentally injured by sharp edges.
● Safety protection device:
1. Equipped with power-off protection function
2. Equipped with upper and lower temperature alarm setting function
3. Low water level protection and alarm function
4. Temperature runaway protection and alarm function
5. The heating device has low water level anti dry burning and explosion-proof functions
6. Multiple protection functions for compressor overheating and overcurrent
Parameter table:
|
model |
Temperature range (℃) |
Temperature fluctuation/uniformity (℃) |
Inner groove size (mm) (Length X Width X Slot Depth) |
Total capacity (L) |
Work slot opening (mm2) |
Cooling capacity (W) Pure water at 20 ℃ |
Circulation mode |
|
XOHW-1015F |
-10~100 |
±0.01~0.005 |
300×250×200 |
15 |
235×160 |
1800 |
U-shaped internal circulation |
Configuration List:
|
sensor |
Samsung AAA rating in South Korea |
|
|
Control instruments |
First European independent research and development |
|
|
refrigeration compressor |
Taikang, France |
|
|
Liquid level switch alarm |
Shanghai Dingxin |
Made of 304 stainless steel |
|
Drain valve |
Zhejiang |
|
|
Heating tube system |
￠12 |
Adopting 304 stainless steel seamless pipe |
|
stainless steel |
304 stainless steel |
|
|
Internal circulation system and external circulation system |
||
|
Internal circulation pump and quantity |
Using Southern Pump Industry |
1 unit |
|
control system |
||
|
System monitoring software |
Nanjing Xianou Instrument Manufacturing Co., Ltd |
1 set |
|
AC contactor |
Chint, Omron |
|
